Channels 8 | Drives/bays 1 | CPU Embedded Linux | Power supply requirements 12 VDC, 1.5 A | Power consumption 10 Watts | Dim. 204.6 × 206.4 × 45.6 mm | Temp. range –10 °C to +55 °C
8 IP channel max, up to 12MP resolution
80Mbps record rate
VGA/HDMI up to 1-channel 12MP @30 fps; 6-channel 1080p @ 30 fps
1 SATA port, up to 16 TB 3.5” HDD, 10/100M LAN
No front panel control, no Alarm I/O, 2 USB
Smart 1U case (white), mouse included
ONVIF (profile T/S/G); CGI; SDK
Connected to the third-party network cameras
4-channel SMD Plus (AI by camera), secondary filtering for human and motor vehicle SMD Plus
Free IP monitoring software available
